Chromite sand
Chromite Sand is a naturally occurring spinel consisting primarily of the oxides of chrome and iron. It is a by-product of ferro-chrome production and is mainly used in foundry applications and in glass production.
It is used as a highly fireproof sharpener for moulds and cores. Originally from South Africa. The sand is produced by crushing chrome ore and its washing in spiral concentrators, subsequent drying, dust cleaning, screening and sorting as per grain size.
- Email:zzhaixu@163.com
- Tel: 8615838373120
- PRODUCTS
- CERAMIC SAND BLASTING BEADS
- Fused Zirconia Plasma Powder
- Fused Yttirum Plasma Powder
- WHITE FUSED ALUMINA
- BROWN FUSED ALUMINA
- PINK FUSED ALUMINA
- ZIRCONIA FUSED ALUMINA
- BLACK SILICON CARBIDE
- FOUNDRY CHROMITE SAND
- GARNET SAND/MICROPOWDER
- BORON CARBIDE
- CERAMIC FOUNDRY SAND
- TABULAR ALUMINA
- GLASS BEADS
- ZIRCON SAND
- GREEN SILICON CARBIDE
hot PRODUCT
CONTACT US
Properties
Physical and chemical index
|
Item |
Unit |
Index |
|
Cr2O3 |
% |
≥46.0% |
|
SiO2 |
% |
≤1.0% |
|
FeO |
% |
≤26.5% |
|
CaO |
% |
≤0.30% |
|
MgO |
% |
≤10.0% |
|
Al2O3 |
% |
≤15.5% |
|
P |
% |
≤0.003% |
|
S |
% |
≤0.003% |
|
Cr/Fe |
1.55:1 |
|
|
Bulk Density |
g/cm³ |
2.5-3 |
|
Color |
/ |
Black |
|
PH |
/ |
7-9 |
|
The amount of the acid |
/ |
≤ 2 ML |
|
Percent soil |
% |
≤0.1 |
|
Percent Moisture |
% |
≤0.1 |
|
The sintered |
℃ |
1600 |
|
Percentage of free acid present in the sand |
% |
0 |
|
Filling density |
g/cm³ |
2.6 |
|
Sintering point |
°C |
> 1,800 |
|
Melting temperature |
°C |
2,180 |
|
Packing |
MT |
1 big bag |
|
Sizes |
|
AFS25-35 AFS25-30 AFS30-35 AFS35-40 AFS40-45 AFS45-50 AFS40-50 AFS50-55 AFS55-60 AFS60-65 |
Application
- Chromite Sand in the foundry industry
- Its properties enable the material to be used in high duty grey iron and steel foundries as core and mould making sand.
- Its high thermal conductivity gives it good chilling properties, low thermal expansion gives rise to good dimensional stability.
- Its basicity being close to neutral allows the use of a wide range of resin bonding systems and inorganic binders, it has a high refractoriness and a broad sieve distribution.
- Chromite Sand in the steel industry
- In steel production, Chromite Sand is used as well filler for protection of the sliding gate in large steel holding ladles.
- Chromite Sand in the glass industry
- When ground to a fine flour, Chromite Sand is used for the production of green glass beverage containers.
