PWA Platelet White Calcined Aluminum oxide
PLATELET WHITE CALCINED ALUMINUM OXIDE IS A PLATELET WHITE CALCINED ALUMINUM OXIDE ABRASIVE POWDER WITH PLATE-SHAPE
- Email:zzhaixu@163.com
- Tel: 8615838373120
- PRODUCTS
- CERAMIC SAND BLASTING BEADS
- SG ABRASIVES
- Fused Zirconia Plasma Powder
- ALUMINA BALL
- Fused Yttirum Plasma Powder
- WHITE FUSED ALUMINA
- BROWN FUSED ALUMINA
- PINK FUSED ALUMINA
- ZIRCONIA FUSED ALUMINA
- BLACK SILICON CARBIDE
- Chromite sand/powder/flour
- GARNET SAND/MICROPOWDER
- BORON CARBIDE
- CERAMIC FOUNDRY SAND
- TABULAR ALUMINA
- GLASS BEADS
- ZIRCON SAND
- GREEN SILICON CARBIDE
hot PRODUCT
CONTACT US
Properties
AVERAGE CHEMICAL COMPOSITION(TYPICAL)
|
Al2O3 |
＞99.0% |
|
SiO2 |
＜0.2% |
|
Fe2O3 |
＜0.1% |
|
Na2O |
＜1% |
PHYSICAL PROPERTIES(TYPICAL)
|
Mohs Hardness |
9.0 |
|
Specific Gravity |
＞3.9g/cm3 |
|
Shape |
Plate-shape |
PARTICLE SIZE DISTRIBUTION
|
SIZE |
D0 |
D3 |
D50 |
D94 |
|
PWA40 |
<77.6 |
39-44.6 |
27.7-31.7 |
18-20 |
|
PWA35 |
<64.2 |
35.4-39.8 |
23.8-27.2 |
15-17 |
|
PWA30 |
<50.4 |
28.1-32.3 |
19.2-22.3 |
13.4-15.6 |
|
PWA25 |
<40.1 |
24.4-28.2 |
16.1-18.7 |
9.6-11.2 |
|
PWA20 |
<32.0 |
20.9-24.1 |
13.1-15.3 |
8.2-9.8 |
|
PWA/WCA15 |
<25.2 |
14.8-17.2 |
9.4-11 |
5.8-6.8 |
|
PWA12 |
<20.3 |
11.8-13.8 |
7.6-8.8 |
4.5-5.3 |
|
PWA09 |
<16.3 |
8.9-10.5 |
5.9-6.9 |
3.3-3.9 |
|
PWA05 |
<12.5 |
6.6-7.8 |
4.3-5.1 |
2.55-3.05 |
|
PWA03 |
<10.0 |
4.8-5.6 |
2.8-3.4 |
1.5-2.1 |
SIZE:PWA40 PWA35 PWA30 PWA25 PWA20 PWA15 PWA12 PWA09 PWA05 PWA03
PACKAGING:TWO 10KGS PLASTIC BAGS IN ONE PAPER BOX,50PAPER BOX ON ONE PALLET
Application
Super finishing silicate grindstone,super finishing Phenol Bond Grindstone, Precision Coated Polishing Tape, Precision Coated Polishing Paper, Hard to Soft Metal Lapping, Optical Plastic Lapping, Filler for Coating, Honing Stones, Gallium Arsenide Lapping, Silicon Lapping, Filler for Heavy Electrical Machinery Parts, Precision Coated Polishing Cloth, lapping agent, compounding agent, coating, Optical Glass Lapping, filter, Quartz Crystal Lapping, abrasive, Silicon Wafer Lapping, Crystal Lapping, Hardened Glass Lens Lapping, Soft Metals Lapping, Super Finishing Vitrified Grindstone
